The Guillotine Hydraulic Steel Plate Shearing Machine is a heavy-duty industrial machine used for cutting steel plates and other metal sheets with high precision and efficiency. It is commonly used in manufacturing, shipbuilding, construction, and metal fabrication industries.

Key Features:

1. Hydraulic Drive System:Provides consistent, powerful shearing force.Ensures smooth operation and precise control over the cutting process.Reduces operator fatigue compared to mechanical or manual shears.

2. Guillotine Design:Features a vertical downward blade (the "guillotine") that cuts through the metal plate.The workpiece is held flat on a bed while the upper blade descends vertically to shear the material.

3. High Shearing Capacity:

- Capable of cutting thick steel plates (typically from 6 mm up to 25–40 mm, depending on model).Maximum plate thickness and width vary by machine size (e.g., 10–25 mm thick × 2000–4000 mm wide).

4. Precision Cutting:Equipped with adjustable back gauge for accurate positioning.CNC (Computer Numerical Control) versions offer automated, repeatable cuts with minimal setup time.

5. Safety Features:Emergency stop buttons.Light curtains or safety guards to prevent operator access during operation.Anti-tilt mechanisms and blade protection systems.

6. Robust Construction:Heavy-duty frame made from cast iron or welded steel for long-term durability.Precision-ground blades ensure clean, straight cuts with minimal burr.

7. Adjustable Blade Gap:Allows optimization based on material thickness and type for better cut quality and reduced wear

8. Optional Accessories:Automatic feeding systems.Multiple blade configurations (e.g., parallel or V-groove blades).Hydraulic or pneumatic clamping systems.

Common Applications:

- Cutting structural steel beams and plates.Fabrication of machinery and equipment frames.Shipbuilding and offshore construction.Automotive and rail industry components.General metalworking shops.

Typical Specifications (Example Model):

| Parameter | Specification |

| Max Shearing Thickness | 25 mm (steel, ≤ 600 MPa) |

| Max Shearing Width | 3000 mm |

| Shearing Force | 1000 kN (or higher) |

| Blade Type | Parallel or V-groove |

| Drive Type | Hydraulic |

| Control System | Manual / PLC / CNC |

| Machine Dimensions (L×W×H) | ~4000 × 1800 × 2500 mm |

| Weight | ~8–12 tons |

Advantages:

High cutting accuracy and repeatability.Fast processing speeds with minimal downtime.Low maintenance due to hydraulic system reliability.Suitable for both small batch and high-volume production.

Maintenance Tips:

Regularly lubricate moving parts and hydraulic cylinders.Inspect and sharpen blades periodically.Check hydraulic fluid levels and replace filters.Ensure proper alignment of the blade and lower bed.

If you're looking to purchase or operate one, it's important to choose a model suited to your specific material thickness, cutting volume, and precision requirements. Reputable manufacturers include CNC Machinery Co., Bosch Rexroth, Jiangsu Hongxing, Yinlong, and Tianjin Daxin.

Let me know if you'd like help selecting a model, comparing brands, or understanding technical drawings/schematics!
